Shelly

Shelly Plus 1PM

Shelly Plus 1PM

$24.00 AUD
$30.00 AUD $24.00 AUD
Sale Sold out
Tax included. Shipping calculated at checkout.
  • We use Australia Post Carbon Neutral Shipping: 2-5 Days $9.99, 1-3 Days $15 or StarTrack Premium $20
  • Order before Midday and we Dispatch the same day
  • Found a Cheaper Price we will Match it

WiFi-operated relay switch, 1 channel 16A, with Power Metering

Control and measure power consumption for wide range of home appliances and office equipment (lights, power lines, security systems, heating radiators, air conditioners, etc.) from anywhere with the smallest WiFi-operated relay switch, with Bluetooth connection

  • Wi-Fi operated - Connects to your Wi-Fi network. No HUB required!
  • Bluetooth - Add devices quick and easy via Bluetooth connection, using Shelly Cloud App
  • Power metering with data storage
  • Wide range of voltages supported
  • Extremely fast processor – ESP32
  • Enhanced safety – Overpower, overvoltage and over-temperature protection
  • Enhanced security - MQTT and WSS support, TLS and custom certificates support
  • Improved API interface

Next Generation Shelly

Enjoy supreme home automation and control with the new generation Shelly devices - Shelly Plus!

Shelly smart relays now come with perfected electrical appliances control through an extremely fast processor, quicker connectivity, improved integration, and enhanced safety! You can now add devices easily via Bluetooth connection, using Shelly Cloud App. Shelly Plus line supports TLS encryption and has an improved shell for standardized support for external sensor plugs.

WARNING:

 All electrical work must be carried out by a licensed electrician under the electrical safety act and AS/NZS300. Doing your own electrical can be dangerous.

POWER
Power supply AC 110-230V ±10%, 50/60Hz
Maximum load 16A
Power supply DC 24 – 240V
SPECIAL FUNCTIONS
Dry contacts No
Roller shutter mode No
Device temperature protection Yes
Overload protection Yes
Power measurement Yes
Working without a neutral line No
FEATURES
HTTP/HTTPS webhooks Yes
Custom scripts(mJs) Yes
Channels 1 Channel
Operational temperature 0°C to + 40 °C
Device power consumption < 1 W
Intelligent On/Off Yes
Local and remote control Yes
Sunrise/Sunset Yes
Weekly Schedule Yes
UL Listed option No
CONNECTIVITY
Wireless Yes
Wi-Fi Protocol 802.11 b/g/n
Wi-Fi Radio frequency 2412 - 2484 MHz
Wi-Fi Radio signal power 1mW
Wi-Fi Range up to 50 m outdoors and up to 30 m indoors (depending on the building materials)
Bluetooth Yes
DIMENSIONS
Size 41mm x 36mm x 15mm



View full details
Google Home
Alexa

Customer Reviews

Based on 6 reviews
50%
(3)
33%
(2)
17%
(1)
0%
(0)
0%
(0)
S
Sean
Should be rated to 10 amps for Brisbane climate

In my experience (engineer) this device is prone to overheat and shut down when operated at 240v 15a in 30c free air. It seems to be reliable so far at 240v 10a, hence the 4 star rating.

The Pro 1PM is better suited to 240v 15a loads due to its superior thermal design. I have measured operating temperatures 20c lower on the Pro model. Spend the extra money if you need to switch 15a at 240v.

P
Phil
Some reliability issues

When it's working it's great. But I have recently experienced a situation where most of my Shelly devices disconnected from the network and became permanently unreachable. Required factory reset for each individual item which is really massively inconvenient when it involved grovelling in the ceiling etc. Sincerely hope this is not a routine occurrence because it was a fair ball ache.

V
Vaughan
Oz Smart Things is the place to buy Shellys Wifi Switches!

Great service, good prices and quick delivery. In my experience Oz Smart Things is the best place to shop for all of your smart home devices.

M
Mark Perrin
Shelly Plus 1 PM

Item arrived in great time, well packaged, and works really well. Starting a foray into Home Automation and this device is the perfect start.

J
Jason

Waiting for built in homekit or matter support. Then they they will be perfect
